Portable fire extinguishers CO2

model	measuring	classification
SH19R	19 mm	Type A, Class 2
SH25R	25 mm	Type A, Class 2

The color of the hose is red. The length of the hose is 30 meters. The maximum working pressure is 12 bar. Proof pressure 24 bar. The minimum burst pressure is 42 bar. The temperature range is from -20°C to +60°C in ambient temperature conditions in a non-aggressive or non-corrosive atmosphere.

Fire hose reels are designed and manufactured in accordance with BS EN671 – 1. Hose reel discs are made of 1.2 mm electro-galvanized steel sheet pre-treated and coated with electrostatic powder coating and oven baked at 200°C. The side panels of the hose reel are protected with a polyester powder coating which meets the salt spray test requirements specified in ISO 9227 for 240 hours. The hose reel drum features a configuration of hydraulically compressed ribs to give extra strength and avoid twisting. The outer edges are turned to give a secure edge treatment on the outer rims and a better look. Automatic Fire Hose Reels are available with an internal valve built into the hose reel unit which opens during 3 turns of the hose reel as the hose is pulled out and closes when the hose is wound back onto the reel.

model	manual	automatic
static type	SF 30 F-19 SF 30 F-25	sf 30 AF-19 sf 30 AF-25
Swing tube type	SF 30 SP-19 SF 30 SP-25	SF 30 A-SP-19 SF 30 A-SP-25
swing arm type	SF 30 SA-19 ​​SF 30 SA-25	SF 30 A-SA-19 ​​SF 30 A-SA-25

SFFECO Fire Hose Angle Valves (90° Pattern) are used on vertical pipes that have the inlet and outlet the same size or with the inlet larger than the outlet. The valve is manufactured according to UL668 hose valve for fire protection service standards. SFFECO UL Listed single and double fire hoses are lined with high-tech EPDM tube whose engineered design ensures minimal weight with maximum durability and flexibility. SFFECO UL Type Adjustable Nozzles are used on Class A and Class B fires in most industrial applications. They are used with a lined fire hose.
