Flanged X Mechanical Joint – 250 PSI

DESCRIPTION MATERIALS SPECIFICATIONS Model LF-WBHX-115 / LF-WBHX-100 Faucet, Wet Barrel Type, 6" Diameter Made of Ductile Iron, with Single 4.5" Pump Connection (4" Pump Connection Optional ). 2.5" Thread Hose Outlet Connections and Connectors , AWWA C503, Flangeless 4" Display, UL\FM Approved, LIFECO Model LF-WBHM-115 / LF-WBHM-100 Faucet, Wet Barrel Type, 6" Diameter Made of Ductile Iron, With Single Pump Connection 4.5” (4″ Pump Connection Optional) Thread and Hose Outlet Connections 2.5” Thread, AWWA C503, With Only 4” Flange Display, UL\FM Approved, LIFECO Features Strong Ductile Iron Material for Long Service Life Pressure Rating Higher at 250psi and 2 times the 500psi test pressure • Choice of multiple hose nozzles • Internal and external fusion bonded epoxy coating • FM approved and UL Listed for use in fire protection application • Observation flange available for additional hardware Technical Specifications • Design Standard: FM1511 / UL246 / AWWA C503 • Nozzle Thread Standard: NFPA1963 • Pressure Working: 250 psi • Inlet Flange Connection in ANSI Class 125/150 6" BS EN 1092-2PN110 / 16 6” • Observation Flange Connection in ANSI Class125/150 4” • Hose Nozzle: 2.5″ * 2 • Nozzle Pump: 4.5” * 1 (4” pump connection optional) • Monitor Flange Connection 2H1PM: ANSI Class125 / 1504 “ BS EN 1092-2 PN10 / 16 4” • Inlet Flange Connection: ANSI CIass125 / 150 6” BS EN1092-2 PN10/16 6” Component Material No. 1 Hydrant Body 65-45-12 2 Steel Wire Rope 3 0 EPDM Ring 4 Fire Engine Nozzle Cap 65-45-12 SS304 Plastic Coated 5 Fire Engine Nozzle C84400 6 Fire Engine Nozzle EPDM Gasket 7 4.5” Gland C F8 8 Inner Flat Angle Set Six Corners Spoiled A 2 9 4.5” EPDM Sealing Ring Disc 10 Disc 4.5” CF8 11 55304/55420 12 Fixed Nut CF8 13 Inner Six Cylinder Angles Head Cover A2.70 14 C84400 15 C & 8 16 Hex Nuts 4.5” Shaft Nut A2.70 17 Hose Nozzle Cap Run Nut
